AUDIOVISUAL
DTH – DIRECT TO HOME
These services allow home aerials to receive TV and radio channels direct from satellites. Satellite DTH ensures robust and reliable communications when it comes to delivering audiovisual TV platform content to end users more efficiently.
HISPASAT has developed flexible, shared-risk models for small DTH operators, who receive income based on the number of subscribers.
UHDTV
As part of its DTH service, HISPASAT has two 4K channels and, since 2017, together with Media Broadcast Satellite it provides 4K distribution services in EMEA via a shared digital platform that is exclusively used for ultra high definition contents.
DISTRIBUTION
In distribution services, once content is received and processed in the satellite broadcasting centre, it is broadcast by the satellite and received and transmitted through terrestrial networks: UHF/VHF, cable systems, microwave systems, etc.
HISPASAT, together with its partners, provides transmission services that can combine satellite technology with terrestrial technologies in order to enable a high-quality, readily available service for customers.
HISPASAT provides distribution services for 152 TV and 73 Radio channels within the coverage offered by all its satellites and across all forms of connectivity
TDT & SOCIAL DTH
HISPASAT provides a TV signal broadcasting service geared towards homes in white space areas. Indeed, HISPASAT satellites complement digital terrestrial television services in countries like Spain, Portugal and Chile.
60,000
DTH Users
4,140
Distribution centres
CINEMA
The HISPASAT and Telespazio solution for distributing digital cinema ensures content integrity and its protection against falsifications and piracy. Based on a two-way content transfer system, the service has been a great success in Italy.
700
Cinemas
CONTRIBUTION
This service consists of content transmission from ground stations, either fixed or itinerant, to other ground stations, normally fixed and known as central ground stations, to later be processed.
HISPASAT’s occasional services provide satellite capacity for satellite contribution from portable ground stations (DSNGs, Flyaways) for limited time fractions, offering a high-quality and readily available service.
In addition, HISPASAT occasional services enable IP connectivity for hours with full bandwidth ensured.
.
PUSH VoD NEW SERVICE!
PUSH VoD: Push VoD is a new service from HISPASAT that enables a linear TV operator to broaden their product offering with on-demand video contents. It is of particular interest for those users that do not have Internet connectivity.
BENEFITS:
- Offers VoD services to users without broadband.
- Efficient content delivery (multicast).
- Compatible with DVB and can be integrated with DTH platforms and other onboard solutions (transport sphere).
- Modular design, can be integrated with STB using existing CAS.
- Compatible with any video or audio format supported by the STB.
- Easily integrated with other technologies.
DATA
IP TRUNKING
HISPASAT satellites offer network operators the option to create high-capacity trunk links. The availability of these links is ensured through monitoring systems at the company’s control centres.
HISPASAT can establish backup links via satellite for customers that need to ensure service continuity, thus guaranteeing the maximum availability of their communications networks.
MOBILE BACKHAUL
HISPASAT offers mobile telephone network operators the flexibility to deploy or expand their networks in time- and cost-efficient ways, connecting remote or inaccessible locations via satellite. This service is complemented with a global solution for the deployment of their networks, including backbone network connections and IP access, depending on the needs of each project.
Moreover, in those regions where HISPASAT has Ku and Ka bands available, the company is promoting hybrid cellular backhaul solutions to leverage the intrinsic characteristics of each frequency band.
INTERNET ACCESS
HISPASAT offers a satellite communications link that can be used by telecommunications operators to get direct and secure access to the Internet backbone, thereby offering broadband connectivity to its customers:
- In neglected areas, thus favouring universal internet access.
- Eliminating congestion on current networks.
- Cutting costs caused by reserving lines or fibre optic.
AVAILABLE BUSINESS MODELS
SPACE CAPACITY
HISPASAT provides satellite capacity (MHz) while operators look after deploying the requisite infrastructure to provide the service.
MANAGED SERVICES
HISPASAT provides an end-to-end solution by offering bandwidth capacity (Mbps) through its communications platforms.
28,147
Terminals
In managed services, the solution is based on a Virtual Network Operator (VNO) in which:
- The customer acts as a VNO and remotely accesses the HISPASAT platform to automatically provide its services to end users.
- HISPASAT, acting as a Hosting Network Operator (HNO), sells dedicated capacity: broadband slots (Mbps).
- The end-user terminals are the customer’s responsibility, and they can buy, install, maintain and register them on platforms.
OTHER INTERNET ACCESS APPLICATIONS
VoIP and video-conference
HISPASAT offers engineering and support services for customers to configure end user terminals to ensure voice/video-conference priority (real time service) over data services.
OVER 7,143
Terminals
TV and multicast data
Geared to customers that need to distribute content cost effectively to particular points in a specific region. The content is encapsulated in IP on HISPASAT’s broadband platforms, and is later uploaded to the satellite and then broadcast to the end user.
Unlimited browsing
HISPASAT has developed a solution to enable client traffic filtering by protocol. With this the user experience is improved, because the volume of data from pure browsing and e-mail is not deducted from the contracted monthly allowance. Only high consumption applications are counted and users can browse and check their e-mail at the nominal contracted speed, even when they go over their monthly allowance.
TRIPLE PLAY
HISPASAT’s Triple play solution via satellite enables voice, video and data services to be implemented with a single user aerial operating in the same orbital position.
- Reception of TV services via Ku band.
- Transmission and reception of data services via Ka.
INTERNET OF THINGS (IoT):
HISPASAT offers space capacity services and managed services for telemetry and remote control systems that enable the remote measurement of physical quantities and parameters, and subsequently send information to the system operator.
Satellite services in the IoT sector have numerous uses in the energy industry.
These services can be offered in remote locations and in transport contexts (such as on ships, in connected cars, trains, etc.).
HOTSPOTS WIFI NEW SERVICE!
The WiFi hotspot solution provides connectivity in public areas (libraries, kiosks, town halls, etc.), which enables the provision of value-added services to the general public.
This service includes the solution of residential WiFi hotspots to provide residential broadband services to homes. This solution is based on a WiFi hotspot that provides homes located within the coverage range, whether or not they have equipment to boost the WiFi signal, with an Internet connection.
HISPASAT is working on developing an educational content solution for classrooms through an indoor WiFi hotspot.
TRANSPORT
Maritime: For commercial vessels, fishing boats, oil rigs, yachts, etc. In this sector it is worth mentioning the positive contributions of HISPASAT to maritime routes in the Mediterranean, the North Sea, the Baltic Sea and the Gulf of Mexico. Highlights: 92 ships
Ground: Trains, buses and other ground transport. In this market it is worth highlighting HISPASAT as a leading provider of mobility solutions in the railway sector. Highlights: 50 trains
Aeronautical: Commercial and military aeroplanes, UAVs and helicopters
VNO mobility services (rail and maritime) HISPASAT offers Virtual Network Operator (VNO) mobility platform services for transport customers. The main solution marketed is based on platforms with technical services and certifications adapted to mobile settings.
As a complement to the VNO platform for mobility services, HISPASAT, together with several strategic partners, developed the product Go Mobile.
Go Mobile is an advanced platform including different services, mainly aimed at train and commercial ship operators that require a “turnkey” product with a complete service proposal:
- Internet access service: Internet access via satellite that can be combined with other technologies (3G, 4G).
- VoD: Video on-demand services stored on internal servers that are updated periodically.
- Video multicast: TV channels broadcast via satellite, in IP to be distributed to passengers.
- Mobile backhaul in mobility: Different solutions depending on the scenario.
- Corporate and security services: Emergency networks, corporate VPN, etc.
- Services portal: Enables access, payment and management of content by end users.
EMERGENCIES
Scenarios:
- Restoring communications during a catastrophe: In this case, architecture similar to IP trunking or Internet access is often implemented.
- Backhauling of emergency terrestrial networks: Solutions that complement TETRA, 3G-4G, and WIMAX services in these situations.
- Communications emergency-related mobile resources: Applies to means of transport by land, air and sea.
1092
Terminals
Marketing models
VNO SLOT: Customers have a VNO slot on one of the broadband platforms, along the same lines as the model for other services such as Internet access.
OCCASIONAL IP: Customers pay a reserve sum (to be agreed) that guarantees capacity availability over a particular period.
Products
ONTIME EASY DEPLOY: This solution comprises a broadband terminal and an Easy Deploy antenna. It is ideal for terrestrial network backhauling such as Tetra or WIMAX, as well as for offering connectivity to advance command posts when managing emergencies and natural disasters.
ONTIME MOBILE: iDIRECT broadband platform for customers in the emergencies market that use mobile resources: Sea rescue, border management, air services such as fighting forest fires, for instance.
ONTIME HELICOPTERS: Helicopter-specific solution.
HISPASAT has signed an agreement with GETSAT to develop services for transport, emergencies and defence.
GETSAT’s sat on the move terminal means that links can be established quickly and efficiently in mobility scenarios.
Advantages: electronic alignment, smaller size and wide range of Ka and Ku frequencies.
OTHER SOLUTIONS
RF MEASUREMENT
Functionality built in to SIGO (Integrated Operations Management System) that allows the measurement of different radio frequencies for customers’ carriers:
- Peak: maximum level adjustment for the carrier
- POL: polarisation adjustment
The service uses the redundant fleet monitoring infrastructure to take measurements.
It allows customers to autonomously verify the correct alignment, reducing the risk of interference and making it possible to deploy a network quickly.
HOUSING
HISPASAT has additional infrastructure at its telecommunications centres to provide a housing service to those customers who need to install additional equipment to provide services to their end customers
